Dynamic balance test of rotors such as small-sized motors, small fan motors, OA machine motors, household appliances, hard disks, DVD disks, micro-motors, fractional horsepower motors, and power tools.

key word:

Rotor dynamic balancing machine Anti-magnetic balancing machine Rotor dynamic balancing machine Fan motor balancing machine

Classification:

Universal series dynamic balancing machine

Email:

lzx@zxjsb.com

Consulting service
Contact us
  • Description
  • Image display
  • Product parameters
  • Customer site
  • Troubleshooting
  • 公司官网主页图片
    Dynamic balance test of rotors such as small-sized motors, small fan motors, OA machine motors, household appliances, hard disks, DVD disks, micro-motors, fractional horsepower motors, and power tools.

    Brand: Zhuo Xuanjin

    Model: YYQ-5DW

    Workpiece mass range (kg): 5

    Maximum outer diameter of the workpiece (mm): Φ120

    Distance between two support seats (mm) Φ280

    Support shaft diameter range (mm) Φ6/18

    Ring belt drive shaft diameter range (mm) Φ40/95

    Rotation speed (r/min) at a workpiece transmission diameter of 100 mm: 800/2000

    Equipment power supply: AC220V50-60HZ 500VA

    Minimum reachable residual imbalance (e mar): ≤0.2g·mm/Kg

    Unbalance reduction rate (U RR)%: 95%
    YYQ-5DW 卧式硬支撑自动定位平衡机
    High-precision positioning without marking
    Automatic tracking of the number of slots technology, will not cause positioning errors due to belt slippage
    Windows Chinese measurement software, you can log in 100 kinds of specifications, call it at any time.
    Free of reflective marking, USB data export, N multiple data storage, flexible positioning
    Touch screen display, easy to touch, simple and beautiful
    Increase/de-weight can be switched at will, easy to use
    Automatic marking system (optional), can also display left and right positioning angle difference
    The device is equipped with automatic diagnosis and easy maintenance.

  •

    Specification

    Parameter

    Workpiece mass range (kg)

    0.5/5

    Maximum outer diameter of the workpiece (mm)

    Φ200

    Distance between two supports (mm)

    15/300

    Support shaft diameter range (mm)

    Φ3/30

    Ring diameter range of the belt drive (mm)

    Φ20/90

    Rotation speed (r/min) at a workpiece transmission diameter of 100 mm

    Stepless speed regulation

    Motor power (KW)

    0.05/0.4servo

    Minimum reachable residual imbalance (e mar )

    ≤0.2g·mm/Kg
    Unbalance reduction rate (U RR)%

    95%
